Intensifier and Cathode-Ray Tube Technologies
Book chapter

Intensifier and Cathode-Ray Tube Technologies

Mohammad A. Karim, A. F. M. Yusuf Haider and A. F. M. Yusuf Haider
Electro-Optical Displays, pp.1-18
CRC Press, 1
1992

Abstract

Electron Gun Phosphor Screen Image Tube Flat Panel Display Brightness Gain Ocular Lens Electron Trajectory Micro-channel Plate Photocathode Surface Fiber Optic Plate Fiber Optic Faceplate Anode Aperture Acceptance Angle Cathode Loading Angular Magnification Phosphor Cells Contrast Ratio Luminous Efficiency Aluminum Backing Television Pickup Tubes MCP Image Intensifier Tube MTF CRT Display
This chapter deals with the physics and engineering aspects of both of the devices, which are at the heart of the many displays and display issues. The limitations to its applicability are controlled only by the density of detector elements on the retina and by its inherent aberrations. A portion of this limitation can be subdued with the assistance of instruments such as binoculars or a telescope by increasing the angular magnification but at the expense of the total viewing angle. Direct-view electronic image intensifiers can be used to rectify the problems that otherwise plague devices such as a binocular by accumulating a larger fraction of the available photons, using these more effectively. A single-stage image intensifier tube consists of an image sensor, an electron lens, a phosphor screen. The simplest version of an image tube is referred to as either biplanar or proximity focused. An objective lens collects the scene information and focuses onto the photo-cathode of the tube.
